ORION-CONVERT offers the necessary tools for broadcasters to create and deliver the HDR and SDR content consumers expect from a single master HDR workflow by providing critical controls required to set up the right conversion for your production. By being able to set the HDR and SDR reference anchor points in an HDR to SDR conversion, you can target an SDR program output that suits your market's SDR display needs. You can target 200 nits SDR resulting in a much more representative image for the camera shader and a more vibrant HDR image for the viewer at home or target a perceptual match at 100 nits SDR. Also, in an HDR to SDR conversion, the unique 2 stage knee offers a pre-conversion compression in HDR only and a post-conversion compression in SDR only providing very effective roll off management control. This is a licensable upgrade and includes:

Conversions utilizing floating point math for higher precision results
SDR, HLG, and PQ transforms
Scene-light and Display-light modes
2 stage Knee adjustment for pre and post conversion compression or expansion
Compression amount control in HDR to SDR conversions
Expansion amount control in SDR to HDR conversions
Configurable SDR and HDR reference anchor points
HDR Peak Nit sets the system gamma for display light conversions
Easy to configure pixel perfect round tripping
Clamping options
Full bypass node for 12G-SDI and HDMI
Support for ITU BT.2408-0, Operational Practices in HDR Television Production
This toolset enables HDR workflows to be set up and easily replicated utilizing ColorBox preset import and export capabilities.
