Eartec EVADE XTreme EVXT7 Industrial Full-Duplex Wireless Intercom System with 2 Dual-Ear Headsets (2.4 GHz)

EVADE Xtreme are self-contained full-duplex wireless headsets used across a multitude of industrial applications where protective hardhat or bump caps are required. To operate the Xtreme simply adjust the headband strap for the correct amount of holding tension, your safety cap fits right over as normal. Once you install the battery just turn the headset "ON", and you are ready to communicate with the rest of your crew in full duplex mode, that is simultaneously and hands free within a ¼ mile range!

As with the Single and Double Series, the EVADE Xtreme features a compact full duplex radio built inside the earcups eliminating belt packs. They also include a septagonal earcup shaped design that is so unique it has received formal patent protection by the US Trademark Office. In addition, Xtreme ear pads are ergonomically formed, that means wider and slightly thicker in the lower rear providing the most comfortable fit of any headset on the market.

EVADE Xtreme team communication wireless systems are popular communication tools for crane & utility crews as well as avionics and defense contractors that need hands free communication. Amidst the din and clatter of the most demanding industrial jobsite EVADE Xtreme will come through, "loud and clear".



Excellent performance - Range up to 1/4 mile

Radio installed inside earcup, no wires or beltpacks

Li-Poly Batteries - Provide continuous 8 hr operation and are field replaceable

Auto Mute Boom - Mute when in UP position

Volume Control - Simple up / down push button adjustment

Sealed for use outdoors in inclement conditions

Light Industrial Design - Wear comfortably for an 8 hour work shift

Field Programmable - Start small and add to your system as needed
Specifications

Frequency Range

2407MHz-2475MHz

Data Rate

1MBPS

Bandwidth

150KHz

Channel Spacing

1MHz

Modulation Type

GFSK

Gain of Antenna

0db

Duplexing

Time Division Duplex (TDD)

Speech Encoding

ADPCM/16kbit/s

RF Accessing

Time Division Multiple Access (TDMA)

Power Supply

Rechargeable Li-polymer Battery @ 3.7v/1000mAH

RF Output Power

80mw

Operating Temperature

0 - +50º C

Operating Relative Humidity Range

30% - 90%

Operation Current

110mA

Operation Time

8h

Range

350m (open field)
