Blackmagic Professional decoder for receiving H.264 streams from ATEM or Blackmagic cameras and converting them to SDI and HDMI video

* Includes tally, camera control and Blackmagic Cloud streaming.

Blackmagic Streaming Encoder is an all in one hardware H.264 and H.265 encoder so you can go live to streaming platforms such as YouTube, X, Facebook or even the Blackmagic Cloud with new streaming features!
It lets you output HD and Ultra HD up to 2160p60 via the 12G-SDI input, plus a built in down converter, USB-C webcam output, HDMI monitoring output and support for Ethernet, 4G and 5G mobile networks.
You can also use the Blackmagic Streaming Decoder to create a streaming link for broadcast purposes, which receives and converts H.264 or H.265 streams to SDI video. You can also send talkback, camera control and tally to the camera!

Streaming has never been easier
Blackmagic Streaming Encoder is a standalone solution that includes a powerful hardware encoder and a software utility with multiple presets.
Connecting to any streaming platform is easy because you don't need a computer with complex streaming software and hundreds of settings.
Simply connect an SDI video source from a live production switcher, then connect to the internet using the built in ethernet or your smartphone's cellular network.
With presets for popular platforms, all you have to do is enter a streaming code and hit On Air!

Stream to YouTube, Facebook and more
Blackmagic Streaming Encoder works with all major streaming platforms.
The built in hardware streaming engine has been carefully designed to deliver professional broadcast quality live streaming.
It's the perfect all-in-one solution for going live without dropped frames.
It is easily configured using the Blackmagic Streaming Utility where you can select your platform and update your streaming code.
The utility works on Mac and Windows and can be connected via USB or remotely via Ethernet.
If you are technically inclined you can also edit the presets stored in an XML file to change settings or add additional streaming platforms.

Online with 5G or 4G mobile phone networks
For maximum flexibility when broadcasting from a remote location or as a backup to your primary Ethernet connection, connect to the internet using your phone's mobile data!
For tethering simply connect your phone to the USB-C port on the front or rear panel.
In addition to 4G, the new high speed 5G phones are also supported.
If your internet connection drops, Blackmagic Streaming Encoder will automatically switch to the connected phone's cellular network.
You can also choose whether to prioritize the Ethernet connection or the phone's connection.
Blackmagic Streaming Encoder is the perfect solution for tethered and mobile data broadcasting from remote locations!

USB Webcam Output for Video Software
Blackmagic Streaming Encoder features two USB-C connections that act as webcam video outputs, so you can plug it into your computer and work with your favorite video software.
Your computer will see the Streaming Encoder as a regular webcam, even though it is actually a broadcast quality SDI video source!
This gives you full resolution compatibility with any video software in 720p HD, 1080p HD or 2160p Ultra HD.
Imagine connecting Blackmagic Streaming Encoder to Microsoft Teams, Zoom or Webex and making broadcast quality video calls to your clients!
Blackmagic Streaming Encoder works with any video software that uses a webcam.

Built-in Technical Monitoring
Traditional transmitters are essential for broadcast television, but streaming servers are now essential for millions of viewers around the world!
That's why Blackmagic Streaming Encoder includes a built-in technical monitoring output.
The monitor shows video, precise audio levels, progress graphs for codec data rates and cache, a summary of streaming settings and detailed SDI connection information.
The output supports both SDI and HDMI, so you can use an SDI matrix switcher for monitoring from multiple locations in the studio or simply connect to an HDMI television monitor.

Connections
SDI Reference Inputs: 1
SDI Video Outputs: 1
SDI Reference Outputs: 1
SDI Transmission: 1.5G, 3G, 6G, 12G
HDMI 2.0 Video Outputs: 1
Streaming Audio Inputs/Outputs:
- 2 channels of embedded streaming audio out
- 2 channels of embedded program audio in
- 2 channels of embedded talkback audio in
SDI Audio Inputs: 16 channels of embedded audio on 12G-SDI Ref In
SDI Audio Outputs:
- 16 channels of embedded audio on 12G-SDI Ref Out
- 2 channels of embedded audio on 12G-SD Out
HDMI Audio Outputs: 8 channels of embedded audio on Monitor Out
Webcam Outputs: 1 x USB-C @ 2160p60 max
Ethernet: BASE-T 10/100/1000 for live streaming, configuration and software updates

Standard
HD Video Input Standard:
720p50, 720p59.94, 720p60,
1080i50, 1080i59.94, 1080i60,
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60,
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
2K video standards:
2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI,
2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI
Ultra HD Video Input Standard: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
Standard 4K video: 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI
SDI standard compliance: SMPTE 259M, SMPTE 274M, SMPTE 292M, SMPTE 296M SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B
Video input color space: Rec. 709, Rec. 2020
3G SDI: SMPTE level A or B automatically detected on SDI input
HDMI HD video standards:
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Ultra HD HDMI video standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p62
4K HDMI video standards: 4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI.
Color Accuracy: 4:2:2
HDMI Color Space: YUV
Streaming Video Standards:
720p25, 720p30, 720p50, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60

Streaming
Direct Streaming: Receives H.264 streams (RTMP) or H.265 (SRT) from Blackmagic Streaming Encoder or compatible Blackmagic cameras
Closed Captioning: Web Presenter 4K supports embedding CEA-608 and CEA-708 closed captions into the live RTMP stream
Timecode: Supports source timecode via RTMP and SRT streams on 12G-SDI Out

Control
Control Panel: Built-in control panel with 6 buttons, rotary knob and 2.2 inch color display
Device Control: Front Panel, USB-C or Ethernet
External Control:
- Supports remote camera control, color corrector, tally and talkback.
- REST API via ethernet for external control with HTTP when used with REST client applications

Software
Compatible services: Facebook, Twitch, YouTube, Twitter, Restream.IO, Vimeo, BoxCast, Castr, AfreecaTV, Bilibili, DouYu, Weibo, Zoom, Skype, Microsoft Teams, QuickTime Player, FaceTime, OBS Studio, Open Broadcaster, VLC, Wirecast Play, Wowza Streaming Engine.

Power Requirements
Power: 1 x 100-240V AC internal
DC 12V Input: 1 x 4-pin XLR DC +12V for external sources or batteries
Power Consumption: TBA

Environmental Specifications
Operating Temperature: 0° to 40° C
Storage Temperature: -20° to 45° C
Relative Humidity: 0% to 90% non-condensing
